Heat Exchangers are designed and manufactured to facilitate indirect heat transfer between the two fluids. The
two fluids can be liquid and liquid or vapor and liquid. The shell-and-tube heat exchanger has two main areas
Tube side and Shell side
Esco Engineering Pvt. Ltd. is a proven Shell and Tube Heat Exchanger manufacturer.
Main components of Shell and Tube type heat exchanger are- Shell, Tube, Tube sheet, Baffles, Tie roads spacers and Channel.
The cylindrical shell can be fabricated from rolled plate or from pipes.
Tubes can be plain tubes. Or heat transfer surface area of the tubes can be increased many folds by using
finned tubes or corrugated tubes. Shell tube heat exchanger with fin tubes are known as finned type heat
exchanger and with corrugated tubes it is known as corrugated tube heat exchanger.
Tubes of heat exchangers are sourced from the reputed manufacturer.
Tubes of the heat exchanger will be held on both the sides by Tube sheets. Tubes will be inserted through holes provided on tube sheets. Tubes are firmly fitted in the tube sheet either by welding or by mechanical or hydraulic expansion.
Baffles are provided to support the tubes, to maintain the space between the tubes and it also channelized the fluid flow as per design through the shell side of heat exchanger.
Tie rods and spacers will hold the baffle assembly together; and will also maintain the spacing between the baffles. One end of the tie rods are secured to the tube sheet and other ends are secure in the last baffle.
Channels or heads are provided for shell-and-tube heat exchangers to contain the tube side fluid and to provide the desired flow path.
Shell and tube heat exchangers are used as condensers, reboilers, process heaters, coolers and falling film evaporator.
Heat Exchangers can be selected based on various types of Tubes such as
Tube, Shell and Tube Sheet MOC can be Copper, Brass, Cupro Nickel, MS, CS, SS304, SS316,
Titanium, etc
Various Applications such as Steam, Compressed Air, Water, Oil, Acid, Paint, Gas, Brine, etc.
Tubes can be plain tubes. Or heat transfer surface area of the tubes can be increased many folds by using
finned tubes or corrugated tubes. Shell tube heat exchanger with fin tubes are known as finned type heat
exchanger and with corrugated tubes it is known as corrugated tube heat exchanger.
Tubes of heat exchangers are sourced from the reputed manufacturer.
Tubes of the heat exchanger will be held on both the sides by Tube sheets. Tubes will be inserted through holes provided on tube sheets. Tubes are firmly fitted in the tube sheet either by welding or by mechanical or hydraulic expansion.
Baffles are provided to support the tubes, to maintain the space between the tubes and it also channelized the fluid flow as per design through the shell side of heat exchanger.
Tie rods and spacers will hold the baffle assembly together; and will also maintain the spacing between the baffles. One end of the tie rods are secured to the tube sheet and other ends are secure in the last baffle.
Channels or heads are provided for shell-and-tube heat exchangers to contain the tube side fluid and to provide the desired flow path.
Shell and tube heat exchangers are used as condensers, reboilers, process heaters, coolers and falling film evaporator.
Esco can offer you a wide variety of electrical exchangers in special construction fully in accordance with
clients specifications and requirements. Electric circulation heaters and process heating systems for heating a
wide range of industrial liquids and gases. They consist of Electric Heater Bundle and Vessel.
Mechanical design codes include ASME, BIS, TEMA, or any other recognized code.
Flange Size | : | To suit customer process requirement |
Flange Rating | : | 150-300-600-900-1500-2500 |
Flange MOC | : | CS, SS 304, SS 310, SS 316, SS 321 |
Flange Standard | : | ANSI/ASME/DIN |
Shell MOC | : | CS, SS 304, SS 310, SS 316, SS 321 |
Degree Protection of Enclosure | : | IP 67 |
Dia of Heating Elements | : | 8.5mm, 12.5mm, 16mm |
Element MOC | : | CS, SS 304, SS 310, SS 316, SS 321, Inconel 600, Incoloy 800 |
Immersion Length | : | Upto 6000mm |
Control & Monitoring | : | Integrally Provided with Thermocouple or PT100 RTD, Thermostat Optionally Provided with TT |
Area Classification | : | Safe Area/Ex'd' Zone 1/Zone 2 , IIA/IIB/IIC, T6 |
Heat Duty | : | To suit customer process requirement |
